S10 Sprinkler
As If It Is Raining
S10 sprinkler will be with you for years with its durable structure! High resistance to chemicals, UV rays and impact is provided.
About the Product
It offers ease of use in projects with different nozzle options
Manufactured from plastic and stainless materials suitable for heavy outdoor conditions. High resistance to chemicals, UV rays and impact is provided.
Bringing Life to the Soil
S10 Sprinkler with you for years with its durable structure!
Technical Specifications
-
Thanks to its low flow rate, specially designed wing and nozzle structure, it prevents water accumulation and hard layer formation on the land surface.
-
It offers ease of use in projects with different nozzle options.
Shapes Water, Gives Life to Soil!
The above data are for windless environment. A homogeneous irrigation requires a minimum working pressure of 2.5 bar.
Nozzle & Flow Specifications
• Offers easy usage in projects with nozzle options suitable for different flow rates.
| Code | Nozzle Diameter (mm) | Flow Rate (L/H) | Box | Box Dimensions (W-D-H) |
||
|---|---|---|---|---|---|---|
| 2,5 Bar | 3,0 Bar | 3,5 Bar | ||||
| S10-S-1 | 2,8 x 1,8 | 740 | 802 | 898 | 175 | 43-33-27 |
| S10-S-2 | 3,2 x 1,8 | 855 | 938 | 1011 | 175 | 43-33-27 |
| S10-S-3 | 3,2 x 2,3 | 1188 | 1303 | 1397 | 175 | 43-33-27 |
| S10-S-4 | 2,5 x 1,8 | 594 | 646 | 709 | 175 | 43-33-27 |
Application Range (AxB)
| Nozzle (mm) | Pressure (Bar) | Flow Rate (L/H) | Diameter (m) | AxB - (mm/h) | |||||
|---|---|---|---|---|---|---|---|---|---|
| 9x9 | 9x10 | 10x10 | 9x12 | 10x12 | 12x12 | ||||
| 2,5 x 1,8 | 2,5 | 594 | 21 | 7,3 | 6,6 | 5,9 | 5,5 | 5,0 | 4,1 |
| 3,0 | 646 | 22 | 8,0 | 7,2 | 6,5 | 6,0 | 5,4 | 4,5 | |
| 3,5 | 709 | 23 | 8,8 | 7,9 | 7,1 | 6,6 | 5,9 | 4,9 | |
| 2,8 x 1,8 | 2,5 | 740 | 21 | 9,1 | 8,2 | 7,4 | 6,9 | 6,2 | 5,1 |
| 3,0 | 802 | 22 | 9,9 | 8,9 | 8,0 | 7,4 | 6,7 | 5,6 | |
| 3,5 | 898 | 23 | 11,1 | 10,0 | 9,0 | 8,3 | 7,5 | 6,2 | |
| 3,2 x 1,8 | 2,5 | 855 | 21 | 10,6 | 9,5 | 8,6 | 7,9 | 7,1 | 5,9 |
| 3,0 | 938 | 22 | 11,6 | 10,4 | 9,4 | 8,7 | 7,8 | 6,5 | |
| 3,5 | 1011 | 23 | 12,5 | 11,2 | 10,1 | 9,4 | 8,4 | 7,0 | |
| 3,2 x 2,3 | 2,5 | 1188 | 21 | 14,7 | 13,2 | 11,9 | 11,0 | 9,9 | 8,3 |
| 3,0 | 1303 | 22 | 16,1 | 14,5 | 13,0 | 12,1 | 10,0 | 9,0 | |
| 3,5 | 1397 | 23 | 17,2 | 15,5 | 14,0 | 12,9 | 11,6 | 9,7 | |
